Running NVIDIA SANA-WM on RTX 5090 and H100

NVIDIA SANA-WM is a 2.6B-parameter open-source world model that generates minute-scale 720p videos with precise 6-DoF camera control. Unlike standard text-to-video models, SANA-WM takes a single image and camera trajectory as input, producing immersive first-person walkthrough videos.

We tested SANA-WM on two GPU configurations:

• RTX 5090 (32GB VRAM) — RunPod community cloud
• H100 SXM (80GB VRAM) — RunPod secure cloud

Our orchestration framework sana_WM handles the full setup, inference, and result download over SSH from a local WSL environment.

---

Input Images

We used four diverse scenes to test SANA-WM’s capabilities:

---

RTX 5090 Results (32GB VRAM)

The RTX 5090 can only run stage-1 generation due to VRAM constraints. The second-stage refiner (which requires ~75GB VRAM) must be disabled using --no_refiner --offload_vae.

Mansion Walkthrough — Progressive Duration Test

Why RTX 5090 Fails at 30+ Seconds

Attempting 30-second generation (481 frames) on RTX 5090 results in CUDA Out of Memory:

torch.OutOfMemoryError: CUDA out of memory.
Tried to allocate 1.2 GiB. GPU has 31.74 GiB total,
28.6 GiB used by model + latents.

Key limitations:

• Stage-1 only (no refiner) → visible artifacts and temporal drift
• 32GB VRAM exhausted at ~400 latent frames
• Longer videos show increasing blur and scene morphing

---

H100 Results (80GB VRAM)

The H100 SXM runs the full two-stage pipeline including the 17B-parameter refiner, producing significantly higher quality output.

Mansion Walkthrough — Progressive Duration Test

Key improvements over RTX 5090:

• ✅ Sharper textures with refiner
• ✅ Reduced temporal drift
• ✅ 30-second generation possible
• ✅ Better scene consistency

---

H100 — Other Scenes (20 Seconds)

---

Experimental: Long-Duration Video (40s)

We attempted a 60-second Mars interior walkthrough, but hit OOM during the refiner stage (~80GB required for 961 latent frames). Reducing to 40 seconds (641 frames) succeeded.

60s OOM Analysis:

VRAM breakdown for 60s (961 frames):
- Stage-1 model: ~15GB
- Refiner (17B LTX-2): ~25GB
- 961 latent frames: ~40GB
- Total: ~80GB (at limit!)

---

Experimental: 360° Panoramic Rotation

We tested whether SANA-WM could generate a stationary 360° rotation — the camera fixed in place, rotating to reveal the full environment.

Why 360° Rotation Fails

Both attempts show the camera drifting horizontally rather than rotating in place:

1. Training data bias: SANA-WM was trained primarily on egocentric walkthrough videos (forward movement + turns), not tripod-style panoramas
2. Action string semantics: The d-N action encodes “turn right N degrees while walking” — there’s no pure “rotate in place” primitive
3. Temporal model limitations: The model hallucinates forward motion to maintain temporal coherence with its training distribution

Workaround: For true 360° panoramas, consider NVIDIA Lyra 2.0 which explicitly supports orbital trajectories.

---

Summary: RTX 5090 vs H100

Metric	RTX 5090 (32GB)	H100 SXM (80GB)
Max video duration	~20s	~40s
Refiner enabled	❌ No	✅ Yes
Typical quality	Blurry, drift	Sharp, stable
Cost (RunPod)	~$1.50/hr	~$3.00/hr
20s video cost	~$0.10	~$0.10
Best use case	Quick tests	Production

Recommendation: Use H100 for any video over 10 seconds or where quality matters. RTX 5090 is viable for rapid prototyping under 20 seconds.

---

Getting Started

Full setup instructions and config examples: github.com/tech-microcosm/sana_WM

# Clone and configure
git clone https://github.com/tech-microcosm/sana_WM.git
cd sana_WM
cp .env.example .env
# Edit .env with your RunPod pod IP and SSH port

# Run inference
python main.py infer -c config/examples/mansion_wm_simple.yaml \
    --host <pod-ip> --port <ssh-port>
